Shining 3D - EinScan-SE V2 3D Scanner
£1,110.00
£925.00
Master powerful, easy-use scanning technology to create precise 360° 3D models of a range of objects from simple structures to even the most elaborate structures.
SKU
S3D-000001
EinScan-SE V2 3D Scanner
A powerful companion for educators and individuals
- Easiest 3D scanning experience for non-technical users
- Dual scan modes: Auto Scan and Fixed Scan
- Easy to operate and great price-to-performance ratio
Compatible with 3D printers
- Auto meshing to watertight 3D data
- Seamlessly connect to 3D printers
- Provide API access service for any brand 3D printers.
Fine Details
Every scan generates a high-quality 3D data.
Reconstruct the real geometry of the object with fine details.
Easy Operation, User Friendliness, and Faster Scanning
One-click scanning
Automatic calibration with no rigid set-up required
1 second for a single scan
45 seconds for a 360-degree scan under auto scan mode
Extensive post-processing functions
Software of EinScan-SE/SP V2 has the functions of filling holes, smoothing and sharpening, and can also readjust the data coordinates in the post-processing process to provide more perfect 3D data for subsequent applications.
EXScan S for macOS
Support for macOS
Intuitive Trackpad Gestures
Background Cutting Function
Quick Alignment
Updated UI Interface
Various Align Modes
TECHNICAL SPECIFICATION
| Scan Modes |
With Turntable: Feature; Manual; Turntable Without Turntable: Feature; Manual |
| Single Shot Accuracy | ≤0.1 mm |
| Minimum Scan Volume | 30 × 30 × 30 mm |
| Maximum Scan Volume |
Fixed Scan: 700×700×700mm Auto Scan: 200×200×200mm |
| Single Scan Range | 200×150 mm |
| Scan Speed |
Single Shot: <1 s Turntable: <45 s |
| Point Distance | 0.17 mm ~ 0.2 mm |
| Texture | Yes |
| File Format | OBJ, STL, ASC, PLY, 3MF |
| Camera Resolution | 1.3 Mega Pixels |
| Light Source | White Light |
| Stand-off Distance | 290 ~ 480 mm |
| Computer Requirements (Required) | USB:1 ×USB 2.0 or 3.0; OS: Win7, 8 or 10 (64 bit); Graphic Card: Nvidia series; Graphic memory: ＞1G; CPU: Dual-core i5 or higher; Memory: ＞8G |
| Computer Requirements (Recommended) | Graphics card: NVIDIA GTX660 or higher； Graphics memory: ＞2 G; CPU: Dual Core I5 or higher; Memory: ＞16 G |
| Weight (unpacked) | 2.5 kg |
| Weight (packed) | 4.9 kg |
| Dimension | 570×210×210 mm |
| Power Supply | 40 w |
| Input Voltage | DC：12 v, 3.33 A |
| Calibration Board | Standard |
| Turntable | Standard |
| Load Capacity of Turntable | 5 kg |
| Manufacturer | Shining 3D |
|---|---|
| Scan Mode | Fixed & Auto Scan |
| Stand-off Distance | 290 ~ 480 mm |
| Weight (unpacked) | 2.5 kg |
| Weight (packed) | 4.9 kg |
| Dimension | 570×210×210 mm |
| Power Supply | 50 w |
| Input Voltage | DC：12 v, 3.33 A |
| Calibration Board | Standard |
| Turntable | Standard |
| Light Source | White Light |
| Camera Resolution | 1.3 Mega Pixels |
| File Format | OBJ, STL, ASC, PLY |
| Mode of Alignment | Feature, Manual, Turntable |
| Single Shot Accuracy | ≤0.1 mm |
| Minimum Scan Volume | 30 × 30 × 30 mm |
| Maximum Scan Volume | Fixed: 700 ×700 × 700mm / Auto: 200×200×200mm |
| Range of Single Capture | 200×150 mm |
| Scan Speed | Fixed: <8 s / Auto: <2 min |
| Point Distance | 0.17 mm ~ 0.2 mm |
| Texture | Yes |
| Load Capacity of Turntable | 5 kg |
