DFRobot - RGB LED Breakout (3528)

RGB LED Breakout (3528) is a compact full‑color lighting module designed for makers, embedded developers, and product designers seeking simple integration of vivid visual indicators. The small breakout board combines a high‑quality RGB LED with convenient pin access, enabling rapid prototyping of lighting effects, status indicators, and colorful displays. PWM signal control enables flexible color mixing across red, green, and blue channels, generating a broad spectrum including orange, yellow, cyan, and white. This miniature lighting board pairs easily with platforms such as Arduino, microcontrollers, and robotics controllers, providing an efficient solution for adding dynamic illumination to interactive electronics projects.

Full‑Color PWM Lighting Control

This RGB lighting breakout supports pulse‑width modulation across independent red, green, and blue channels, allowing precise brightness and color control. PWM‑driven mixing produces smooth gradients and a wide palette of colors ranging from soft ambient tones to bright indicator signals. Such flexibility makes this compact RGB LED module suitable for status displays, mood lighting, and interactive feedback systems. Integration with common microcontroller platforms enables programmable animations, color transitions, and responsive lighting behaviors for prototyping environments and embedded system development.

Wide Viewing Angle with Optimized Light Coupling

A high‑quality 3528 RGB LED package combined with an internal reflector structure enhances light diffusion and coupling efficiency. The wide viewing angle ensures clear visibility from multiple directions, improving readability for indicator lights or decorative lighting elements in enclosures and panels. The white LED package also enhances brightness and color clarity. Such optical design makes this miniature LED breakout suitable for robotics indicators, interactive installations, control panels, and compact electronics projects requiring consistent visual output.

Typical uses include robotics status indicators, colorful user‑interface lighting, embedded system feedback signals, and creative electronics prototyping. The compact breakout board format simplifies integration into breadboards and custom PCBs, supporting rapid experimentation in maker projects, product concept validation, and STEM Education environments where visual feedback enhances learning and debugging.

• Programmable full‑color RGB LED module
• PWM control enables dynamic color mixing and brightness adjustment
• Wide viewing angle for improved visibility
• Compact breakout board design for rapid prototyping
• Compatible with common microcontroller platforms
• White LED package for improved color clarity
• Suitable for embedded indicators and decorative lighting

• Robotics status indicators
• Interactive electronics lighting effects
• Embedded system visual feedback
• Control panel indicator lights
• Prototype user‑interface displays
• Creative maker and STEM learning projects

• Full color RGB LED
• Operating Voltage:3.3-5V
• Wide viewing angle
• White package
• Operating Temperature:-40℃ to +85℃
• Size:13x13mm(0.51x0.51")

• RGB LED Breakout(3528) ×1
• Straight pin header 4p ×1
