GNSS Receiver - EM-506N5

The EM-506N5 GPS receiver from USGlobalSat based on the MediaTek high performance L1 band GNSS receiver. This is the new version from the EM-506. It includes on-board voltage regulation, LED status indicator, battery backed RAM, and a built-in patch antenna! 6-pin interface cable not included.

This EM-506N5 GPS module is powered by the MediaTek high performance L1 band GNSS receiver, it can provide you with superior sensitivity and performance even in urban canyon and dense foliage environment.

Not sure which GPS module is right for you? Check out our GPS Buying Guide!

Features:

• Sensitivity:
  • Tracking: -165dBm
  • Acquisition (Cold Start TTFF): -148dBm
• Hot Start - Autonomous: <1 sec, average
• Warm Start - Autonomous: <15 sec
• Cold Start - Autonomous: <35 sec
• Main Power Supply (VCC): Min. 4.5V, Typ. 5V, Max. 6.5V
• Main Power Supply Current:
  • Typ. 32mA, Max. 36mA - GPS is not 3D Fixed.
  • Typ. 29mA, Max. 35mA - GPS is 3D Fixed.
• GPS L1CA/QZSS L1CA/SBAS L1/Galileo E1 (E1B+E1C): 1575.42 MHz
• GLONASS L10F: 1602 MHz
• BeiDou B1: 1561.098 MHz
• Horizontal Position Accuracy- Autonomous: <2.5m
• Velocity Accuracy:
  • Speed: <0.05 m/s
  • Heading: <0.01 degrees
• Reacquisition: 0.1 second, average
• Update Rate: 1 Sec / 5 Sec
• Maximum Altitude: <18,000 meter
• Maximum Velocity: <500 meter/second
• Maximum Acceleration: <4G
• Humidity Range: Min. 5, Max. 95 % non-condensing
• Operation Temperature: Min. -40°C, Typ. 25°C, Max. 85°C
• Storage Temperature: Min. -40°C, Max. 85°C

Documents:

• Datasheet
