LSLidar - N401
Reflector Navigation LiDAR
N401 can identify high or low reflectance object,
which is mainly applied in navigation of AGV or unmanned forklift with reflective board.
Full Scanning
360º
Detection Range
10m/30m/50m
Eye Safety
Class 1
Accuracy
+- 3
Output Data
Distance, Angle
Anti-Glare
Indoor and outdoor applications
Resistant to the Shock and Vibration
The N401 Lidar has passed the rigorous accelerated shock test and was certificated, the drop of height with acceleration is until 40g, much higher than the one normally requested of 10g.
That is higly appreciated by some applications such as autonomous driving, AGV and forklifts, which really need to avoid being damaged during the running, loading, unloading, and transportation operations, then finally improve the safety.
| FOV | Scan Rate |
| 360º | 5Hz / 10Hz / 20Hz |
| Data Acquisition Rate | Resolution |
| 20,000 pts/s | 5Hz:0.09º, 10Hz:018º, 20Hz:0.36º |
| Shock | Working Temperature |
| 500m/sec², Lasts 11ms | -20ºC ~ 60ºC |
| Vibration | |
| 5Hz-2000Hz, 3G rms |
