LSLidar - CH32 Auto-grade Hybrid-solid State LiDAR
£1,688.90 £1,407.42
SKU
LS-CH32
Brand
Secured and trusted checkout with
Related Products
Check items to add to the cart or
LSLidar - CH32
32-line Hybrid-solid State LiDAR
Auto-grade Standard
Provide More Extreme and Accurate Perception Performance for Self-driving
32 Lines
High Resolution Modeling
Horizontal
0.045°@5Hz, 0.09 °@10Hz °, 0.18° @20Hz
Vertical
0°~ 0.81° (ROI mini 0.09°, max 0.47°)
120° x -6.67°~4.58°
Wide FOV
200m
Long Range Detection
100/150/200m
Range
426,000 pts/s(Single Return)
Data Acquisition Rate
±2cm
Accuracy
10W
Power Consumption
-40℃ ~ 85℃
Working Temperature
IP67
IP Rating
Embedded Styling
More Fits the Vechicle Body Design
High Reliability & Stability
Compared to mechanical LiDAR, most parts in CH series LiDAR are solid components, with only one rotation prism, which greatly improve the durability and assembly efficiency, and more likely to achieve large scale production.
Point Cloud
Security
Perimeter Security System
Security
3D Protection System
Autonomous Driving
Multi-sensor Fusion Perception System
Smart Logistics
Multi-Robots Coordination System
ITS
V2X Roadside Perception System
Rail Transportation
Railway Intrudment Inspection System (Train End)
Rail Transportation
Railway Intrudment Inspection System(Road End)
ITS
High-way ETC Activation System
